LP 110

A baler for high throughput

Introduction
Specifications
Options

This baler is ideal for high-material throughput applications. The LP 110 baling press is, like all our models, extremely robust, reliable and durable.

The baler is available in four different versions – with two feed opening sizes and two bale sizes (for more information see Specifications tab). The LP 110 can process up to 55 tonnes/hour and has a combined press force of up to 164 tonnes.

Model
Press force (prepress + main press)
Feed opening
Bale size
Capacity ton/hour with 50 kg/m3
Electric motor
LP 110 CH2
54+110
1650x1100
1100x750
15-18
2x45
LP 110 CH4
54+110
1650x1100
1100x750
17-21
2x55
LP 110 CH6
54+110
1650x1100
1100x750
18-22
2x75
LP 110 CH2S
54+110
1650x1100
1100x1100
20-24
2x45
LP 110 CH4S
54+110
1650x1100
1100x1100
24-28
2x55
LP 110 CH6S
54+110
1650x1100
1100x1100
25-29
2x75
LP 110 DH2
54+108
2050x1100
1100x750
15-18
2x45
LP 110 DH4
54+108
2050x1100
1100x750
17-21
2x55
LP 110 DH2S
54+108
2050x1100
1100x1100
18-22
2x45
LP 110 DH4S
54+108
2050x1100
1100x1100
23-28
2x55

This baler is available with these options:

Plastic strapping unitTying unit for polypropylene wire.
Waste designHardened steel plates in the baler’s friction chamber in order to prolong the lifespan of the baler when baling hard-wearing materials like waste and PET.
Cross strapping unitUnit for strapping the bale from a second direction – in order to get high bale density when baling expanding materials like plastic.
Please contact me about LP 110

    Strapping material
